KA87DT90L4/BMG/THEV1A SEW Eurodrive

Technical details

1. Availability 0 pcs
2. Brand SEW Eurodrive
3. Item number KA87DT90L4/BMG/THEV1A SEW Eurodrive
4. Category Geared AC Motors

Weight and Dimensions

1. Weight (kg) 110

Product Properties

1. Rated power (kW) 1.5
2. Speed at 50Hz (rpm) 1500 / 4-Poles
3. Frequency 50 Hz
4. Energy efficiency IE1 = standard = EFF2
5. Brake AC Brake
6. IP Class IP54
7. Explosion safety (Atex) No protection
8. Gear ratio i = n1/n2 174

Detailed Product Properties

1. Voltage 220-230VD / 380-400VY
2. Housing material Cast Iron
3. AC/DC AC
4. Standard IEC
