HF100L423046060B5R Rossi

Technical details

1. Availability 0 pcs
2. Brand Rossi
3. Item number HF100L423046060B5R Rossi
4. Category 3-Phase Motors

Weight and Dimensions

1. Weight (kg) 24.7

Product Properties

1. Rated power (kW) 3.6
2. Speed at 50Hz (rpm) 1500 / 4-Poles
3. Frequency 60 Hz
4. Energy efficiency Not applicable
5. Mounting non standard
6. Brake No Brake
7. IP Class IP55
8. Explosion safety (Atex) No protection
9. IEC Framesize 100

Detailed Product Properties

1. Shaft diameter (mm) 24
2. Shaft height IEC in JDE 100
3. Shaft length (mm) 50
4. Shaft key width (mm) 8
5. Shaft key length (mm) 50
6. Thread shaft bore M10
7. Shaft height, B3 mounted (mm) 100
8. Width foot holes, B3 mounted (mm) 160
9. Length foot holes, B3 mounted (mm) S=286, M=311
10. Outer diameter flange B5/V1/B35/V3 (mm) 200
11. Pitch circle diameter B5/V1/B35/V3 (mm) 215
12. Number of flange holes 4
13. Pitch circle diameter B14/B34/V18/V19 (mm) 130
14. Thread flange holes B14/B34/V18/V19 M8
15. Outer diameter flange B14/B34/V18/V19 (mm) 160
