3F2A-80MA-6B5 Felstrom

80-6P 0,37kW 230/400V B5 AL

Stock
not in stock
Brand Felstrom
Article number 3F2A-80MA-6B5 Felstrom
Rated power 0.37kW
Mounting B5 (outer flange)
Frequency 50/60 Hz
Speed (RPM) 1000 / 6-Poles
Product description

The 3F2A-80MA-6B5 Felstrom has no unwelcome surprises in store. The solid, versatile design guarantees top performance in a variety of situations. Its integrated PTC resistors protect this electric motor with B5 mounting position against overloads.

Felstrom electric motors combine their secure and solid construction with a very friendly price level. They also work extremely efficiently. All Felstrom motors have the highest possible efficiency class per power category and fully comply with European regulations. With the 3F2A-80MA-6B5 Felstrom you choose for carefree ease-of-use and an excellent price/quality ratio.

Help with this product

Similar to: 3F2A-80MA-6B5 Felstrom

Product
Dimensions/Properties
Stock
Price ex VAT
3GAA083001-BSE ABB
3GAA083001-BSE ABB
Guaranteed same day shipment on orders placed before 18:00h (CET)
133,85 ex VAT
  • Rated power 0.37kW
  • Mounting B5 (outer flange)
  • Frequency 50/60 Hz
  • Speed (RPM) 1000 / 6-Poles
3GAA083001-BSE ABB
Guaranteed same day shipment on orders placed before 18:00h (CET)

1 pc
133,85 ex VAT

Product specifications

Technical details

  1. Availability 0 pcs
  2. Brand Felstrom
  3. Item number 3F2A-80MA-6B5 Felstrom
  4. EAN 8719735013903
  5. Category 3-Phase Motors

Weight and Dimensions

  1. Weight (kg) 9

Product Properties

  1. Rated power (kW) 0.37
  2. Speed at 50Hz (rpm) 1000 / 6-Poles
  3. Frequency 50/60 Hz
  4. Energy efficiency IE2 = High = EFF1
  5. Mounting B5 (outer flange)
  6. Brake No Brake
  7. IP Class IP55
  8. Explosion safety (Atex) No protection
  9. IEC Framesize 80

Detailed Product Properties

  1. Voltage 220-230VD / 380-400VY
  2. IEC Framesize 80
  3. Shaft diameter (mm) 19
  4. Housing material Alu
  5. AC/DC AC
  6. Standard IEC
  7. Shaft height IEC in JDE 080
  8. Shaft length (mm) 40
  9. Shaft key width (mm) 6
  10. Shaft key length (mm) 32
  11. Thread shaft bore M6
  12. Shaft height, B3 mounted (mm) 80
  13. Width foot holes, B3 mounted (mm) 125
  14. Length foot holes, B3 mounted (mm) 100
  15. Diameter foot holes (mm) 9.5
  16. Outer diameter flange B5/V1/B35/V3 (mm) 200
  17. Spigot B5/V1/B35/V3 (mm) 130
  18. Pitch circle diameter B5/V1/B35/V3 (mm) 165
  19. Number of flange holes 4
  20. Diameter flange holes B5/V1/B35/V3 (mm) 12
  21. Pitch circle diameter B14/B34/V18/V19 (mm) 100
  22. Thread flange holes B14/B34/V18/V19 M6
  23. Outer diameter flange B14/B34/V18/V19 (mm) 120
  24. Spigot B14/B34/V18/V19 (mm) 80
