3F1A-63MA-2B34 Felstrom

59,61 ex VAT
€ 72,12 in VAT
€ 72,12 in VAT
59,61 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CEST)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

3F1A-63MA-2B34 Felstrom

63-2P 0,18kW 230V/400V B34 AL

Stock
1 pc in stock and ready for shipment
Brand Felstrom
Article number 3F1A-63MA-2B34 Felstrom
Rated power 0.18kW
Mounting B34 (foot + inner flange)
Frequency 50/60 Hz
Speed (RPM) 3000 / 2-Poles
Product description

The 3F1A-63MA-2B34 Felstrom has no unwelcome surprises in store. The solid, versatile design guarantees top performance in a variety of situations. Its integrated PTC resistors protect this electric motor against overloads. In addition, this Felstrom motor with B34 mounting position has removable feet. By removing the feet, this type can also be used as a motor with a B14 mounting position. There is no price difference between the B34 and B14 version of this motor.

Felstrom electric motors combine their secure and solid construction with a very friendly price level. They also work extremely efficiently. All Felstrom motors have the highest possible efficiency class per power category and fully comply with European regulations. With the 3F1A-63MA-2B34 Felstrom you choose for carefree ease-of-use and an excellent price/quality ratio.

Help with this product

Similar to: 3F1A-63MA-2B34 Felstrom

Loading similair products

Product specifications

Technical details

  1. Availability 1 pc
  2. Brand Felstrom
  3. Item number 3F1A-63MA-2B34 Felstrom
  4. EAN 8719735012616
  5. Category 3-Phase Motors

Weight and Dimensions

  1. Weight (kg) 3.9

Product Properties

  1. Rated power (kW) 0.18
  2. Speed at 50Hz (rpm) 3000 / 2-Poles
  3. Frequency 50/60 Hz
  4. Energy efficiency IE1 = standard = EFF2
  5. Mounting B34 (foot + inner flange)
  6. Brake No Brake
  7. IP Class IP55
  8. Explosion safety (Atex) No protection
  9. IEC Framesize 63

Detailed Product Properties

  1. Voltage 220-230VD / 380-400VY
  2. IEC Framesize 63
  3. Shaft diameter (mm) 11
  4. Housing material Alu
  5. AC/DC AC
  6. Standard IEC
  7. Shaft height IEC in JDE 063
  8. Shaft length (mm) 23
  9. Shaft key width (mm) 4
  10. Shaft key length (mm) 16
  11. Thread shaft bore M4
  12. Shaft height, B3 mounted (mm) 63
  13. Width foot holes, B3 mounted (mm) 100
  14. Length foot holes, B3 mounted (mm) 80
  15. Diameter foot holes (mm) 7
  16. Outer diameter flange B5/V1/B35/V3 (mm) 140
  17. Spigot B5/V1/B35/V3 (mm) 95
  18. Pitch circle diameter B5/V1/B35/V3 (mm) 115
  19. Number of flange holes 4
  20. Diameter flange holes B5/V1/B35/V3 (mm) 10
  21. Pitch circle diameter B14/B34/V18/V19 (mm) 75
  22. Thread flange holes B14/B34/V18/V19 M5
  23. Outer diameter flange B14/B34/V18/V19 (mm) 90
  24. Spigot B14/B34/V18/V19 (mm) 60
Show all details Show less
