1LE1603-2CA23-4AB4-Z Siemens

Name: 1LE1603-2CA23-4AB4-Z Siemens
Brand: Siemens

€ 4.029,90 ex VAT

€ 4.876,18 in VAT

€ 4.029,90 ex VAT

	Guaranteed same day shipment on orders placed before 18.00h (CET)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

1LE1603-2CA23-4AB4-Z Siemens

250-2P 55kW 400/690V B3 CI

Stock	1 pc in stock and ready for shipment
Brand	Siemens
Article number	1LE1603-2CA23-4AB4-Z Siemens
Rated power	55kW
Mounting	B3 / 1M1001 (foot)
Frequency	50/60 Hz
Speed (RPM)	3000 / 2-Poles

Product description

SIMOTICS SD MOTOR TYPE: 1CV3252A Low-voltage motor, IEC Squirrel-cage rotor, self-ventilated, IP55 Temperature class 155(F) according to 130(B) cast iron frame Performance line Premium Efficiency IE3, 2-pole * Size 250M * 55kW (50 Hz) 62kW (60 Hz) 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 3, 3 PTC thermistors for disconnection (2 terminals) Terminal box at top R11=Terminal box rotated by 90°, entry from NDE NDESIMOTICS SD MOTOR TYPE: 1CV3252A Low-voltage motor, IEC Squirrel-cage rotor, self-ventilated, IP55 Temperature class 155(F) according to 130(B) cast iron frame Performance line Premium Efficiency IE3, 2-pole * Size 250M * 55kW (50 Hz) 62kW (60 Hz) 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 3, 3 PTC thermistors for disconnection (2 terminals) Terminal box at top R11=Terminal box rotated by 90°, entry from NDE NDE
