1LA7083-4AA12 Siemens

Technical details

1. Availability 0 pcs
2. Brand Siemens
3. Item number 1LA7083-4AA12 Siemens
4. Category 3-Phase Motors
5. Manufacturer Part Number (MPN) 1LA7083-4AA12
6. Weight (kg) 10
7. Rated power (kW) 0.75
8. Mounting B14 (inner flange)
9. Speed at 50Hz (rpm) 1500 / 4-Poles
10. Frequency 50/60Hz
11. IP Class IP55
12. Brake No Brake
13. Explosion safety (Atex) No protection
14. IEC Framesize 80
15. Energie efficiency IE1 = standard = EFF2
16. Voltage 220-230VD / 380-400VY
17. Housing material Alu
18. IEC Framesize 80
19. Shaft diameter (mm) 19
20. Shaft length (mm) 40
21. Wedge width (mm) 6
22. Wedge length (mm) 32
23. Thread shaft bore M6
24. Shaft height, B3 mounted (mm) 80
25. Width foot holes, B3 mounted (mm) 125
26. Length foot holes, B3 mounted (mm) 100
27. Diameter foot holes (mm) 9,5
28. Outer diameter flange B5/V1/B35/V3 (mm) 200
29. Diameter edge B5/V1/B35/V3 (mm) 130
30. Pitch flange holes B5/V1/B35/V3 (mm) 165
31. Number of flange holes 4
32. Diameter flange holes B5/V1/B35/V3 (mm) 12
33. Outer diam. flange B14/B34/V18/V19 (mm) 120
34. Diam. edge B14/B34/V18/V19 (mm) 80
35. Pitch holes flange B14/B34/V18/V19 (mm) 100
36. Thread flange holes B14/B34/V18/V19 M6
