| Product |
| Article Number (Market Facing Number) |
1FT6084-8WH71-4AH1 |
| Product Description |
SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 35 NM, 100 K, 4500 RPM WATER-COOLED; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL DRIVE END INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); PLAIN SHAFT, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END |
| Product family |
Not available |
| Product Lifecycle (PLM) |
PM410:Product cancellation |
| PLM Effective Date |
Product is cancelled since: 01-10-15 |
| Notes |
Sucessor:Product obsolet. No replacement product
|
| Price data |
| Price Group / Headquarter Price Group |
103 / 762 |
| List Price |
Show prices |
| Customer Price |
Show prices |
| Metal Factor |
------71 |
| Delivery information |
| Export Control Regulations |
ECCN : N / AL : N |
| Delivery Time |
40 Day/Days |
| Net Weight (kg) |
24,504 Kg |
| Product Dimensions (W x L x H) |
Not available |
| Packaging Dimension |
Not available |
| Package size unit of measure |
Not available |
| Quantity Unit |
1 Piece |
| Packaging Quantity |
1 |
| Additional Product Information |
| EAN |
Not available |
| UPC |
Not available |
| Commodity Code |
85015230 |
| LKZ_FDB/ CatalogID |
SD.NC60ST-1FT6 |
| Product Group |
9628 |
| Country of origin |
Germany |
| Compliance with the substance restrictions according to RoHS directive |
sinds: 01-07-06 |
| Product class |
C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| Categorie voor terugname electronische materialen na gebruik |
Geen terugname verplichting |
| Classifications |
| |
Not available |
