1AT71-4AB14 Marin & Maskin AB

71-4P 0,25kW 230/400V B14 AL

Stock
not in stock
Brand Marin & Maskin AB
Article number 1AT71-4AB14 Marin & Maskin AB
Rated power kw
Mounting
Frequency
Speed (RPM) rpm
Product description
Read more Show less

Similar to: 1AT71-4AB14 Marin & Maskin AB

Loading similair products

Product specifications

Technical details

  1. Availability 0 pcs
  2. Brand Marin & Maskin AB
  3. Item number 1AT71-4AB14 Marin & Maskin AB
  4. Category 3-Phase Motors
  5. Weight (kg) 6.50
  6. Manufacturer Part Number (MPN) 1AT71-4AB14
  7. Voltage 220-230VD / 380-400VY
  8. Housing material Alu
  9. IEC Framesize 71
  10. Shaft diameter (mm) 14
  11. Shaft length (mm) 30
  12. Wedge width (mm) 5
  13. Wedge length (mm) 22
  14. Thread shaft bore M5
  15. Shaft height, B3 mounted (mm) 71
  16. Width foot holes, B3 mounted (mm) 112
  17. Length foot holes, B3 mounted (mm) 90
  18. Diameter foot holes (mm) 7
  19. Outer diameter flange B5/V1/B35/V3 (mm) 160
  20. Diameter edge B5/V1/B35/V3 (mm) 110
  21. Pitch flange holes B5/V1/B35/V3 (mm) 130
  22. Number of flange holes 4
  23. Diameter flange holes B5/V1/B35/V3 (mm) 10
  24. Outer diam. flange B14/B34/V18/V19 (mm) 105
  25. Diam. edge B14/B34/V18/V19 (mm) 70
  26. Pitch holes flange B14/B34/V18/V19 (mm) 85
  27. Thread flange holes B14/B34/V18/V19 M6
