0.25K31CI0632B3 WEG

63-2P 0,25kW 230/400V B3 CI

Stock
not in stock
Brand WEG
Article number 0.25K31CI0632B3 WEG
Rated power 0.25kw
Mounting B3 (foot)
Frequency 50/60Hz
Speed (RPM) 3000rpm
Product description
Read more Show less
Help with this product

Similar to: 0.25K31CI0632B3 WEG

Loading similair products

Product specifications

Technical details

  1. Availability 0 pcs
  2. Brand WEG
  3. Item number 0.25K31CI0632B3 WEG
  4. Category 3-Phase Motors
  5. Weight (kg) 12
  6. Manufacturer Part Number (MPN) 0.25K31CI0632B3
  7. Rated power (kW) 0.25
  8. Mounting B3 (foot)
  9. Speed at 50Hz (rpm) 3000
  10. Frequency 50/60Hz
  11. IP Class IP55
  12. Brake No Brake
  13. Explosion safety (Atex) No protection
  14. IEC Framesize 63
  15. Energie efficiency Not applicable
  16. Voltage 220-230VD / 380-400VY
  17. Housing material Cast iron
  18. IEC Framesize 63
  19. Shaft diameter (mm) 11
  20. Shaft length (mm) 23
  21. Wedge width (mm) 4
  22. Wedge length (mm) 16
  23. Thread shaft bore M4
  24. Shaft height, B3 mounted (mm) 63
  25. Width foot holes, B3 mounted (mm) 100
  26. Length foot holes, B3 mounted (mm) 80
  27. Diameter foot holes (mm) 7
  28. Outer diameter flange B5/V1/B35/V3 (mm) 140
  29. Diameter edge B5/V1/B35/V3 (mm) 95
  30. Pitch flange holes B5/V1/B35/V3 (mm) 115
  31. Number of flange holes 4
  32. Diameter flange holes B5/V1/B35/V3 (mm) 10
  33. Outer diam. flange B14/B34/V18/V19 (mm) 90
  34. Diam. edge B14/B34/V18/V19 (mm) 60
  35. Pitch holes flange B14/B34/V18/V19 (mm) 75
  36. Thread flange holes B14/B34/V18/V19 M5
