ZM60 INA

All dimensions

1. Inner (d) MM 0,00
2. Outer (D) MM 80,00
3. Width (B) MM 16,00
4. Inner (d) Inch 0.0000
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.6299
7. Height (H) mm 16,00

Technical details

1. Availability 35 pcs
2. Brand INA
3. Item number ZM60 INA
4. Also known as 0017312110000

5. EAN 4012802439632
6. Category Lock Nut

Weight and Dimensions

1. Weight (kg) 0.25

Data from Schaeffler (medias)

1. Thread (d) M60X2
2. Breaking load, axial (F aB) "255000.0000"
3. Mounting torque set screw (M A) "5.0000"
4. Breakaway (M L) "180.0000"
5. Mounting torque reference (M AL) "100.0000"
6. Mass moment of inertia (M m) "3.4500"
7. ECLASS number 23-05-92-03
8. ECLASS2 number 23-05-92-03
9. Medias description Precision locknut ZM, accessory ZM..
