ZKLN3062-2Z-XL INA

Double direction angular contact thrust ball bearing

Stock
7 pcs in stock and ready for shipment
Brand INA
Article number ZKLN3062-2Z-XL INA
Product description

The ZKLN3062-2Z-XL INA is a double direction angular contact thrust ball bearing. This precision bearing type, also known as an axial angular contact ball bearing, is designed for use in screw drives and other applications requiring high running accuracy and load capacity. The bearing consists of a plastic cage with a double row of balls, a thick-walled outer ring, and a split inner ring. Thanks to the 60-degree contact angle, radial and high axial forces can be absorbed in both directions.

The ZKLN3062-2Z-XL INA is suitable for installation in a housing bore. The bearing’s outer ring is secured with a cover, locknut, or other clamping mechanism. With the ZKLN3062-2Z-XL INA, a compact, rigid bearing arrangement can be achieved that is easy to assemble and disassemble.

Help with this product

Downloads and links

Similar to: ZKLN3062-2Z-XL INA

No similar products found

Product specifications

Suffix description

  1. 2Z Gap Seals At Both Sides Of The Bearing
  2. XL X-Life

Technical details

  1. Availability 7 pcs
  2. Brand INA
  3. Item number ZKLN3062-2Z-XL INA
  4. Also known as 0017778820000
    ZKLN3062-2Z
  5. EAN 4047643182096
  6. Category Angular Contact Thrust Ball Bearings, Double Direction

Data from Schaeffler (medias)

  1. Medias description Axial angular contact ball bearings ZKLN..-2Z, double direction, gap seals on both sides
