ZKLF40115-2RS-XL INA

All dimensions

1. Inner (d) MM 40,00
2. Outer (D) MM 115,00
3. Width (B) MM 46,00
4. Inner (d) Inch
5. Outer (D) Inch
6. Width (B) Inch
7. Width (b) mm 46,00

Suffix description

1. 2RS Rubber Seals At Each Side Of The Bearing
2. XL X-Life

Technical details

1. Availability 8 pcs
2. Brand INA
3. Item number ZKLF40115-2RS-XL INA
4. Also known as 0005400050000
   BEAM040115-2RS
   ZKLF40115-2RS

5. EAN 4012802078824
6. Category Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

1. Weight (kg) 2.2

Product Properties

1. Cage Type P - Plastic Molded Cage
2. Precision P4 Precision (Higher than P5)

Data from Schaeffler (medias)

1. Basic dynamic load rating, axial (C a) "79000.0000"
2. Axial Static Load Rating C0a (N) 149000
3. Basic static load rating, axial (C 0a) "149000.0000"
4. Axial Dynamic Load Rating Ca (N) 79000
5. Limiting speed for grease lubrication (n G Grease) "3500.0000"
6. Thermally safe operating speed (n ϑ) "1600.0000"
7. ECLASS number 23-05-10-02
8. ECLASS2 number 23-05-10-02
9. Medias description Axial angular contact ball bearings ZKLF..-2RS, double direction, for screw mounting, lip seals on both sides
