Z-530689.KL FAG

All dimensions

1. Inner (d) MM 55
2. Outer (D) MM 91,6
3. Width (B) MM 25
4. Inner (d) Inch 2.1654
5. Outer (D) Inch 3.6063
6. Width (B) Inch 0.9843

Suffix description

1. KL Kugellager

Technical details

1. Availability 3 pcs
2. Brand FAG
3. Item number Z-530689.KL FAG
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.549

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. ECLASS number 23-05-08-01
2. ECLASS2 number 23-05-08-01
