VU200260 INA

All dimensions

1. Inner (d) MM 191
2. Outer (D) MM 329
3. Width (B) MM 46
4. Inner (d) Inch 7.5197
5. Outer (D) Inch 12.9528
6. Width (B) Inch 1.811
7. Outside Diameter (D a) mm 329
8. Width inner ring (h i) mm 41
9. Width outer ring (h a) mm 41

Technical details

1. Availability 7 pcs
2. Brand INA
3. Item number VU200260 INA
4. Also known as 0013268050000

5. EAN 4012802137316
6. Category Four Point Contact Ball Bearing

Weight and Dimensions

1. Weight (kg) 15

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides
2. Cage Type S - Steel or Standard Cage
3. External Modification No External Modification
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
7. Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 295000
2. Radial Dynamic Load Rating Cr (N) 165000
3. Axial Static Load Rating C0a (N) 650000
4. Axial Dynamic Load Rating Ca (N) 181000
5. ECLASS number 23-05-14-90
6. ECLASS2 number 23-05-14-90
7. Medias description Four point contact bearings without gear teeth, sealed on both sides
