VEB10 5CE1 DDM SNFA

All dimensions

1. Inner (d) MM 10
2. Outer (D) MM 22
3. Width (B) MM 12
4. Inner (d) Inch 0.3937
5. Outer (D) Inch 0.8661
6. Width (B) Inch 0.4724

Suffix description

1. 5
2. ABEC5 Dimensional and running accuracy to ISO tolerance class 5
3. C Phenolic Resin
4. E External Cage Location
5. 1 CD (SKF)=15° Contact Angle
6. DD Two Bearings Arranged Back-To-Back <>
7. M Moderate Preload (For Symmetrical Sets Only)

Technical details

1. Availability 10 pcs
2. Brand SNFA
3. Item number VEB10 5CE1 DDM SNFA
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.18

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P5 Precision (Higher than P6)
4. Contact Angle 15° Contact High Speed Design
5. Pairing DB - O-arrangement, 2
6. Axial Internal Clearance / Preload GB - Medium Preload
7. Lubrication Standard Lubrication
