UKFL208-J7 FAG

€ 32,59 ex VAT
€ 39,44 in VAT
€ 39,44 in VAT
€ 32,59 ex VAT

11 similar products for UKFL208-J7 FAG in stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

UKFL208-J7 FAG

Housing and Bearing (assembly)

Stock
not in stock
Brand FAG
Article number UKFL208-J7 FAG
Inside diameter 35mm
Outside diameter 175mm
Width 46mm
Product description

The UKFL208-J7 FAG is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: UKFL208-J7 FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 35
  2. Outer (D) MM 175
  3. Width (B) MM 46
  4. Inner (d) Inch 1.378
  5. Outer (D) Inch 6.8898
  6. Width (B) Inch 1.811
  7. Flange width (L) mm 100
  8. Height flange (H) mm 175

Suffix description

  1. J7 This Suffix Is The Standard With A Better Fitting In The Housing

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number UKFL208-J7 FAG
  4. Also known as 0812153630000
    FYTJ40KF
    UK208 + FL208 + H2308
    YSA208-2FK+FYTJ508+H2308
  5. EAN 4047643261975
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.57

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 19800
  2. Radial Dynamic Load Rating Cr (N) 34500
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Flanged housing unit UKFL
