UK210 FAG

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 90
3. Width (B) MM 55
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 3.5433
6. Width (B) Inch 2.1654
7. Outside diameter (D SP) mm 90
8. Width (b) mm 34
9. Locking collar total width (B 1) mm 55

Technical details

1. Availability 28 pcs
2. Brand FAG
3. Item number UK210 FAG
4. Also known as 0705802350000
   YSA210-2FK

5. EAN 4012802662092
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.97

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 23200
2. Radial Dynamic Load Rating Cr (N) 37500
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearings UK, spherical outer ring, location by adapter sleeve, RSR seals on both sides

Downloads and links

1. Link to manufacturer Link to manufacturer
