UCT216-J7 FAG

Name: UCT216-J7 FAG
Brand: FAG

€ 152,60 ex VAT

€ 184,65 in VAT

€ 152,60 ex VAT

	Guaranteed same day shipment on orders placed before 18.00h (CET)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

UCT216-J7 FAG

Housing and Bearing (assembly)

Stock	11 pcs in stock and ready for shipment
Brand	FAG
Article number	UCT216-J7 FAG
Inside diameter	80mm
Outside diameter	184mm
Width	51mm

Product description

The UCT216-J7 FAG is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Start a chat
Call us at: +31 (0)85 00 22 247
Email us at: help@247industries.com Response within 24h

Downloads and links

Link to manufacturer

Similar to: UCT216-J7 FAG

Loading similair products

Product specifications

Inside diameter 80mm
Outside diameter 184mm
Width 51mm

All dimensions

Inner (d) MM 80
Outer (D) MM 184
Width (B) MM 51
Inner (d) Inch 3.1496
Outer (D) Inch 7.2441
Width (B) Inch 2.0079
Height (H) mm 184
Length total (L) mm 235

Suffix description

J7 This Suffix Is The Standard With A Better Fitting In The Housing

Technical details

Availability 11 pcs
Brand FAG
Item number UCT216-J7 FAG
Also known as 0823123540000
UC216 + T216-J7
EAN 4054366901408
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 8.6

Product Properties

Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

ECLASS number 23-05-16-03
ECLASS2 number 23-05-16-03
Medias description Housing units UCT, cast iron housing, radial insert ball bearing with grub screws in inner ring, RSR seals, for linear motion
