UCF205-J7 FAG

€ 19,40 ex VAT
€ 23,48 in VAT
€ 23,48 in VAT
€ 19,40 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

UCF205-J7 FAG

Housing and Bearing (assembly)

Stock
270 pcs in stock and ready for shipment
Brand FAG
Article number UCF205-J7 FAG
Inside diameter 25mm
Outside diameter 95mm
Width 35,8mm
Product description

The UCF205-J7 FAG is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: UCF205-J7 FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 95
  3. Width (B) MM 35,8
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 3.7402
  6. Width (B) Inch 1.4094
  7. Flange width (L) mm 95

Suffix description

  1. J7 This Suffix Is The Standard With A Better Fitting In The Housing

Technical details

  1. Availability 270 pcs
  2. Brand FAG
  3. Item number UCF205-J7 FAG
  4. Also known as 0806730400000
    56205 + FG205S
    FG56205
    FYJ25TF
    GYE25KRRB + CJ05
    RCJY20
    UC205 + F205-J7
    YAR205-2F + FYJ505
  5. EAN 4047643228305
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.719

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 7800
  2. Radial Dynamic Load Rating Cr (N) 14900
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Flanged housing unit UCF

Downloads and links

  1. Link to manufacturer Link to manufacturer
