UC307-104D1 NTN

All dimensions

1. Inner (d) MM 31,75
2. Outer (D) MM 80
3. Width (B) MM 48
4. Inner (d) Inch 1.25
5. Outer (D) Inch 3.1496
6. Width (B) Inch 1.8898

Suffix description

1. D1 Relube Type

Technical details

1. Availability 0 pcs
2. Brand NTN
3. Item number UC307-104D1 NTN
4. Also known as UC307-20

5. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.77

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment
