UC207-23 FAG

All dimensions

1. Inner (d) MM 36,51
2. Outer (D) MM 72
3. Width (B) MM 42,9
4. Inner (d) Inch 1.4375
5. Outer (D) Inch 2.8346
6. Width (B) Inch 1.689
7. Outside diameter (D SP) mm 72
8. Width (b) mm 42,9

Suffix description

1. 23 1.7/16" Bore

Technical details

1. Availability 17 pcs
2. Brand FAG
3. Item number UC207-23 FAG
4. Also known as 0703006660000
   YAR207-107-2F

5. EAN 4012802655933
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.45

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 15300
2. Radial Dynamic Load Rating Cr (N) 27500
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearings UC, spherical outer ring, location by grub screws, RSR seals on both sides
