UC205-14 FAG

All dimensions

1. Inner (d) MM 22,23
2. Outer (D) MM 52
3. Width (B) MM 34,1
4. Inner (d) Inch 0.875
5. Outer (D) Inch 2.0472
6. Width (B) Inch 1.3425
7. Outside diameter (D SP) mm 52
8. Width (b) mm 34,1

Suffix description

1. 14 7/8" Bore

Technical details

1. Availability 38 pcs
2. Brand FAG
3. Item number UC205-14 FAG
4. Also known as 0702976220000
   56205.014
   YAR205-014-2F

5. EAN 4012802654028
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.23

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 7800
2. Radial Dynamic Load Rating Cr (N) 14900
3. Basic static load rating, radial (C 0r) "7800.0000"
4. ECLASS number 23-05-08-02
5. ECLASS2 number 23-05-08-02
6. Medias description Radial insert ball bearings UC, spherical outer ring, location by grub screws, RSR seals on both sides

Downloads and links

1. Link to manufacturer Link to manufacturer
