UC201 FAG

All dimensions

1. Inner (d) MM 12
2. Outer (D) MM 47
3. Width (B) MM 31
4. Inner (d) Inch 0.4724
5. Outer (D) Inch 1.8504
6. Width (B) Inch 1.2205
7. Outside diameter (D SP) mm 47
8. Width (b) mm 31

Technical details

1. Availability 18 pcs
2. Brand FAG
3. Item number UC201 FAG
4. Also known as 0767088880000

5. EAN 4047643051811
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.21

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 6600
2. Radial Dynamic Load Rating Cr (N) 13600
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearings UC, spherical outer ring, location by grub screws, RSR seals on both sides
