TKDM09X145-G2-B-12,5/12,5 INA

All dimensions

1. Outer (D) MM 9
2. Width (B) MM 145
3. Outer (D) Inch 0.3543
4. Width (B) Inch 5.7087

Suffix description

1. 145 Length Of The Guideway In MM
2. G2 Precision Class 2
3. B Guideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B
4. 12,5 Distance Between Beginning Of The Guideway And First Hole In MM
5. /12,5 Distance Between End Of The Guideway And Last Hole In MM

Technical details

1. Availability 5 pcs
2. Brand INA
3. Item number TKDM09X145-G2-B-12,5/12,5 INA
4. Also known as 0925519040000

5. EAN 4054369742510
6. Category Linear Bearing Part

Weight and Dimensions

1. Weight (kg) 0.0435
