TCJT30-XL-N INA

Housing and Bearing (assembly)

Stock
13 pcs in stock and ready for shipment
Brand INA
Article number TCJT30-XL-N INA
Inside diameter 30mm
Outside diameter 142mm
Width 50,2mm
Product description

The TCJT30-XL-N INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: TCJT30-XL-N INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 142
  3. Width (B) MM 50,2
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 5.5906
  6. Width (B) Inch 1.9764
  7. Flange width (L) mm 80
  8. Height flange (H) mm 142
  9. Total height unit (U) mm 50,2

Suffix description

  1. XL X-Life
  2. N Cast Iron Housing With Undercut Slot For End Caps

Technical details

  1. Availability 13 pcs
  2. Brand INA
  3. Item number TCJT30-XL-N INA
  4. Also known as 0008569160000
    TCJT30-N
  5. EAN 4012802799057
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.9

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 11300
  2. Radial Dynamic Load Rating Cr (N) 20700
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Housing units TCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, T seals
