TCJ70-XL INA

€ 214,50 ex VAT
€ 259,54 in VAT
€ 259,54 in VAT
€ 214,50 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

TCJ70-XL INA

Housing and Bearing (assembly)

Stock
10 pcs available for shipment on Wed 14 Jan
Brand INA
Article number TCJ70-XL INA
Inside diameter 70mm
Outside diameter 188mm
Width 82,6mm
Product description

The TCJ70-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: TCJ70-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 70
  2. Outer (D) MM 188
  3. Width (B) MM 82,6
  4. Inner (d) Inch 2.7559
  5. Outer (D) Inch 7.4016
  6. Width (B) Inch 3.252
  7. Flange width (L) mm 188
  8. Total height unit (U) mm 82,6

Suffix description

  1. XL X-Life

Technical details

  1. Availability 10 pcs on Wed 14 Jan
  2. Brand INA
  3. Item number TCJ70-XL INA
  4. Also known as 0947479540000
    GE70-KTT-B + GG.CJ14
    NIP DIN71412-A R 1/8
    NIP DIN71412-B R 1/8
    NIP DIN71412-C R 1/8
  5. EAN 4064327115140
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 5.85

Product Properties

  1. Seal 2T - Two T-seals
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Basic static load rating, radial (C 0r) 44000

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
Show all details Show less
