TCJ50-XL-N INA

Name: TCJ50-XL-N INA
Brand: INA

€ 89,33 ex VAT

€ 108,08 in VAT

€ 89,33 ex VAT

	Guaranteed same day shipment on orders placed before 18.00h (CET)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

TCJ50-XL-N INA

Housing and Bearing (assembly)

Stock	52 pcs in stock and ready for shipment
Brand	INA
Article number	TCJ50-XL-N INA

Product description

The TCJ50-XL-N INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Email us at: help@247industries.com Response within 24h

Downloads and links

Similar to: TCJ50-XL-N INA

Loading similair products

Product specifications

All dimensions

Flange width (L) mm 143
Total height unit (U) mm 66,2

Suffix description

XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps

Technical details

Availability 52 pcs
Brand INA
Item number TCJ50-XL-N INA
Also known as 0009402320000
TCJ50-N
EAN 4012802804430
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 2.53

Product Properties

Seal 2T - Two T-seals
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

Radial Static Load Rating C0r (N) 23200
Radial Dynamic Load Rating Cr (N) 37500
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units TCJ, four-bolt flanged housing units, cast iron, eccentric locking collar, T seals
