TCJ35-XL-N INA

€ 50,50 ex VAT
€ 61,11 in VAT
€ 61,11 in VAT
€ 50,50 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

TCJ35-XL-N INA

Housing and Bearing (assembly)

Stock
29 pcs in stock and ready for shipment
Brand INA
Article number TCJ35-XL-N INA
Inside diameter 35mm
Outside diameter 118mm
Width 53,5mm
Product description

The TCJ35-XL-N INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: TCJ35-XL-N INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 35
  2. Outer (D) MM 118
  3. Width (B) MM 53,5
  4. Inner (d) Inch 1.378
  5. Outer (D) Inch 4.6457
  6. Width (B) Inch 2.1063
  7. Flange width (L) mm 118
  8. Total height unit (U) mm 53,5

Suffix description

  1. XL X-Life
  2. N Cast Iron Housing With Undercut Slot For End Caps

Technical details

  1. Availability 29 pcs
  2. Brand INA
  3. Item number TCJ35-XL-N INA
  4. Also known as 0008572460000
    TCJ35-N
  5. EAN 4012802798722
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.47

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 15300
  2. Radial Dynamic Load Rating Cr (N) 27500
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Housing units TCJ, four-bolt flanged housing units, cast iron, eccentric locking collar, T seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
