SL181884-E INA

Single-row full-complement cylindrical roller bearing

Stock
1 pc available for shipment on 17 May
Brand INA
Article number SL181884-E INA
Inside diameter 420,00mm
Outside diameter 520,00mm
Width 46,00mm
Product description

The SL181884-E INA is a single-row, full-complement cylinder bearing. This bearing type has a solid outer and inner ring and a high number of cylindrical rollers. These rollers are guided between the ribs of the rings. Since there is no cage, the maximum number of rolls can be used. As a result, these bearings can support very high radial loads. However, the maximum speed is lower than the speed of cylindrical roller bearings with cages. Single-row full-complement cylindrical roller bearings can also support axial forces in one direction. They are used as support bearings. Support bearings allow axial displacement of the shaft relative to the housing in one direction. The shaft is located axially in the other direction.

Read more Show less
Help with this product

Downloads and links

Similar to: SL181884-E INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 420,00
  2. Outer (D) MM 520,00
  3. Width (B) MM 46,00
  4. Inner (d) Inch 16.5354
  5. Outer (D) Inch 20.4724
  6. Width (B) Inch 1.8110
  7. Width (b) mm 46,00

Suffix description

  1. E Increased Load Capacity

Technical details

  1. Availability 1 pc on 17 May
  2. Brand INA
  3. Item number SL181884-E INA
  4. Also known as 0153822730000
    NCF1884V
  5. EAN 4012802461411
  6. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 21

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal No Seal
  3. Cage Type FC - Full Complement, No Cage
  4. External Modification No External Modification
  5. Radial Internal Play Cn Normal Internal Play
  6. Precision Standard Precision
  7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 1420000
  2. Radial Dynamic Load Rating Cr (N) 680000
  3. Basic static load rating, radial (C 0r) "1420000.0000"
  4. Limiting speed (n G) "650.0000"
  5. Reference speed (n ϑr) "430.0000"
  6. ECLASS number 23-05-09-01
  7. ECLASS2 number 23-05-09-01
  8. Medias description Cylindrical roller bearing SL1818..-E, full complement roller set, single row, semi-locating bearing, 1 rib on outer ring, 2 ribs on inner ring, type SL18
