SL181834-A-BR INA

Single-row full-complement cylindrical roller bearing

Stock
6 pcs in stock and ready for shipment
Brand INA
Article number SL181834-A-BR INA
Inside diameter 170,00mm
Outside diameter 215,00mm
Width 22,00mm
Product description

The SL181834-A-BR INA is a single-row, full-complement cylinder bearing. This bearing type has a solid outer and inner ring and a high number of cylindrical rollers. These rollers are guided between the ribs of the rings. Since there is no cage, the maximum number of rolls can be used. As a result, these bearings can support very high radial loads. However, the maximum speed is lower than the speed of cylindrical roller bearings with cages. Single-row full-complement cylindrical roller bearings can also support axial forces in one direction. They are used as support bearings. Support bearings allow axial displacement of the shaft relative to the housing in one direction. The shaft is located axially in the other direction.

Read more Show less
Help with this product

Downloads and links

Similar to: SL181834-A-BR INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 170,00
  2. Outer (D) MM 215,00
  3. Width (B) MM 22,00
  4. Inner (d) Inch 6.6929
  5. Outer (D) Inch 8.4646
  6. Width (B) Inch 0.8661

Suffix description

  1. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
  2. BR Black Finished, Factory-Applied Durotect® B Black-Oxide Coating. Durotect B Improves Run-In Behavior And Energy Efficiency While Reducing Surface-Induced Damage To The Bearing, Burnished Race

Technical details

  1. Availability 6 pcs
  2. Brand INA
  3. Item number SL181834-A-BR INA
  4. Also known as 0116710840000
    NCF1834V/L4B
  5. EAN 4012802623895
  6. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 1.87

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal No Seal
  3. Cage Type FC - Full Complement, No Cage
  4. External Modification No External Modification
  5. Radial Internal Play Cn Normal Internal Play
  6. Precision BR - Black Finishing
  7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

  1. ECLASS number 23-05-09-01
  2. ECLASS2 number 23-05-09-01
