SL05024-E INA

All dimensions

1. Inner (d) MM 120,00
2. Outer (D) MM 180,00
3. Width (B) MM 60,00
4. Inner (d) Inch 4.7244
5. Outer (D) Inch 7.0866
6. Width (B) Inch 2.3622

Suffix description

1. E Increased Load Capacity

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number SL05024-E INA
4. Also known as 0017092910000

5. EAN 4054366073334
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 5.2

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type FC - Full Complement, No Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. ECLASS number 23-05-09-01
2. ECLASS2 number 23-05-09-01
