SL045040-D-PP-2NR-C3 INA

All dimensions

1. Inner (d) MM 200,00
2. Outer (D) MM 310,00
3. Width (B) MM 150,00
4. Inner (d) Inch 7.8740
5. Outer (D) Inch 12.2047
6. Width (B) Inch 5.9055
7. Width (b) mm 150,00

Suffix description

1. D Outer Ring Profile Developed Further, With An Enlarged Load Bearing Area And Optimized Edge Transitions
2. PP Lip Seals On Both Sides Of The Bearing
3. 2NR Supplied With Two Loose-Packed Retaining Rings WRE
4. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 2 pcs on 9 May
2. Brand INA
3. Item number SL045040-D-PP-2NR-C3 INA
4. Also known as 0892761400030
   NNF5040B-2LSV/C3

5. EAN 4054369588491
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 42

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2L - LS-seal at Both Sides
3. Cage Type FC - Full Complement, No Cage
4. External Modification 2R - 2 Snap Rings in O.D.
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 2600000
2. Radial Dynamic Load Rating Cr (N) 1350000
3. Basic static load rating, radial (C 0r) "2600000.0000"
4. Limiting speed for grease lubrication (n G Grease) "610.0000"
5. ECLASS number 23-05-09-01
6. ECLASS2 number 23-05-09-01
7. Medias description Cylindrical roller bearing SL04..-D-PP-2NR, full complement roller set, two-row, locating bearing, central rib on outer ring, 3 ribs on inner ring, type SL04
