SL045020-D INA

All dimensions

1. Inner (d) MM 100,00
2. Outer (D) MM 150,00
3. Width (B) MM 67,00
4. Inner (d) Inch 3.9370
5. Outer (D) Inch 5.9055
6. Width (B) Inch 2.6378
7. Width (b) mm 67,00

Suffix description

1. D Outer Ring Profile Developed Further, With An Enlarged Load Bearing Area And Optimized Edge Transitions

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number SL045020-D INA
4. Also known as 0861829780000

5. EAN 4054364897338
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 3.95

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type FC - Full Complement, No Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 550000
2. Radial Dynamic Load Rating Cr (N) 330000
3. Basic static load rating, radial (C 0r) "550000.0000"
4. Limiting speed for grease lubrication (n G Grease) "1300.0000"
5. ECLASS number 23-05-09-01
6. ECLASS2 number 23-05-09-01
7. Medias description Cylindrical roller bearing SL04..-D, full complement roller set, two-row, locating bearing, central rib on outer ring, 3 ribs on inner ring, type SL04
