SL045008-S3-C4 INA

All dimensions

1. Inner (d) MM 40,00
2. Outer (D) MM 68,00
3. Width (B) MM 38,00
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 2.6772
6. Width (B) Inch 1.4961

Suffix description

1. S3 Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +300°C (572°F)
2. C4 Bearing Internal Clearance Greater Than C3

Technical details

1. Availability 6 pcs
2. Brand INA
3. Item number SL045008-S3-C4 INA
4. Also known as 0000785570040
   NNF5008V/S3C4

5. EAN 4026677898630
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.5286

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type FC - Full Complement, No Cage
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Standard Precision
7. Heat Stabilization S3 - Temperatures up to 300 °C

Data from Schaeffler (medias)

1. ECLASS number 23-05-09-01
2. ECLASS2 number 23-05-09-01

Downloads and links

1. Link to manufacturer Link to manufacturer
