SL024920-A INA

Double-row full-complement cylindrical roller bearing

Stock
14 pcs in stock and ready for shipment
Brand INA
Article number SL024920-A INA
Inside diameter 100mm
Outside diameter 140mm
Width 40mm
Product description

The SL024920-A INA is a full-complement double-row cylindrical roller bearing. This bearing has a particularly high radial load capacity. The design consists of a solid inner and outer ring with a double row of cylindrical rollers. These rolling elements are guided between flanges. Since there is no cage, a maximum number of rollers can be used. This type of bearing is therefore suitable for very heavy loads where lower rotational speeds are involved.

Help with this product

Downloads and links

Similar to: SL024920-A INA

Product
Dimensions/Properties
Stock
Price ex VAT
NNCL4920-V NKE
NNCL4920-V NKE
Guaranteed same day shipment on orders placed before 18:00h (CET)
197,81 ex VAT
NNCL4920-V NKE
Guaranteed same day shipment on orders placed before 18:00h (CET)

10 pcs
197,81 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 100
  2. Outer (D) MM 140
  3. Width (B) MM 40
  4. Inner (d) Inch 3.937
  5. Outer (D) Inch 5.5118
  6. Width (B) Inch 1.5748
  7. Width (b) mm 40

Suffix description

  1. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Technical details

  1. Availability 14 pcs
  2. Brand INA
  3. Item number SL024920-A INA
  4. Also known as 0001236760000
    NNCL4920V
  5. EAN 4047643175029
  6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

  1. Weight (kg) 2

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal No Seal
  3. Cage Type FC - Full Complement, No Cage
  4. External Modification No External Modification
  5. Radial Internal Play Cn Normal Internal Play
  6. Precision Standard Precision
  7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 370000
  2. Radial Dynamic Load Rating Cr (N) 191000
  3. Limiting speed (n G) 2700
  4. Reference speed (n ϑr) 1720
  5. ECLASS number 23-05-09-01
  6. ECLASS2 number 23-05-09-01
  7. Medias description Cylindrical roller bearing SL02..-A, full complement roller set, two-row, non-locating bearing, 0 ribs on outer ring (smooth), 3 ribs on inner ring, type SL02
