SL024834-A-2S INA

All dimensions

1. Inner (d) MM 170,00
2. Outer (D) MM 215,00
3. Width (B) MM 45,00
4. Inner (d) Inch 6.6929
5. Outer (D) Inch 8.4646
6. Width (B) Inch 1.7717
7. Width (b) mm 45,00

Suffix description

1. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
2. 2S Bearings Matched In Set Of Two For Side-By-Side Mounting, Tolerance Is Matched Based On The Inner, Outer And Clearance Of The Bearing

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number SL024834-A-2S INA
4. Also known as 0001681490954

5. EAN 4054365554872
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 3.95

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type FC - Full Complement, No Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Set of Two for Side-by-Side
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) "600000.0000"
2. Limiting speed (n G) "1670.0000"
3. Reference speed (n ϑr) "1180.0000"
4. ECLASS number 23-05-09-01
5. ECLASS2 number 23-05-09-01
