SK014-205-KRR INA

All dimensions

1. Inner (d) MM 22,23
2. Outer (D) MM 52,00
3. Width (B) MM 25,40
4. Inner (d) Inch 0.8750
5. Outer (D) Inch 2.0472
6. Width (B) Inch 1.0000
7. Width (b) mm 25,40

Suffix description

1. KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)

Technical details

1. Availability 10 pcs
2. Brand INA
3. Item number SK014-205-KRR INA
4. Also known as 0504194470000
   1725-7/8H
   205KRR2
   YHC205-014-2LS8W

5. EAN 4054366694614
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.2

Product Properties

1. Seal 2L - LS-seal at Both Sides
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 7800
2. Radial Dynamic Load Rating Cr (N) 14900
3. Basic static load rating, radial (C 0r) "7800.0000"
4. ECLASS number 23-05-08-01
5. ECLASS2 number 23-05-08-01
6. Medias description Self-aligning deep groove ball bearings SK..-KRR, Cylindrical outer ring, inner ring with hexagonal bore, R seal on both sides
