SCE88-L271/STD INA

All dimensions

1. Inner (d) MM 12,7
2. Outer (D) MM 17,46
3. Width (B) MM 12,7
4. Inner (d) Inch 0.5
5. Outer (D) Inch 0.687
6. Width (B) Inch 0.5
7. Under roller diameter (F w) mm 12,7
8. Width (C) mm 12,7

Suffix description

1. L271 Shell Retinax LX2 Anti Wear Protection Grease
2. STD Standard Fill

Technical details

1. Availability 63 pcs
2. Brand INA
3. Item number SCE88-L271/STD INA
4. Also known as 0060110390702
   SCE88

5. EAN 4012802070767
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.007

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 9000
2. Limiting speed (n G) 19500
3. ECLASS number 23-05-09-05
4. ECLASS2 number 23-05-09-05
