SCE2620 INA

All dimensions

1. Inner (d) MM 41,275
2. Outer (D) MM 50,8
3. Width (B) MM 31,75
4. Inner (d) Inch 1.625
5. Outer (D) Inch 2
6. Width (B) Inch 1.25
7. Under roller diameter (F w) mm 41,275
8. Width (C) mm 31,75

Suffix description

1. G2 Standard Quality Class For Needles
2. /0-10 Micron - Needle Sort

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number SCE2620 INA
4. Also known as 0060100080000

5. EAN 4047643194662
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.11

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 97000
2. Limiting speed (n G) 6200
3. ECLASS number 23-05-09-05
4. ECLASS2 number 23-05-09-05
