S71917ACEGA/P4A SKF

All dimensions

1. Inner (d) MM 85
2. Outer (D) MM 120
3. Width (B) MM 18
4. Inner (d) Inch 3.3465
5. Outer (D) Inch 4.7244
6. Width (B) Inch 0.7087

Suffix description

1. ACE 25° Contact Angle And (E) Small Size Balls
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 1 pc
2. Brand SKF
3. Item number S71917ACEGA/P4A SKF
4. Also known as 2LA-HSE917AD LLB G/GL P42
   3MMV9317HX VV SUL
   HSS71917E.T.P4S.UL
   VEB85/S 7CE3 UL
   ZSB1917HERRUL

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.52

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25° Contact High Speed Design
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
