S7016CEGA/P4A SKF

All dimensions

1. Inner (d) MM 80,00
2. Outer (D) MM 125,00
3. Width (B) MM 22,00
4. Inner (d) Inch 3.1496
5. Outer (D) Inch 4.9213
6. Width (B) Inch 0.8661

Suffix description

1. CE 15° Contact Angle And (E) Small Size Balls
2. GA Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload
3. P4A Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4

Technical details

1. Availability 6 pcs
2. Brand SKF
3. Item number S7016CEGA/P4A SKF
4. Also known as 2LA-HSE016C LLB G/GL P42
   2MMV9116HX VV SUL
   80BNC10TRV1VLP3
   HSS7016C.T.P4S.UL
   VEX80/S 7CE1 UL
   ZSB116HCRRUL

5. EAN 7316575949259
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.9

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15° Contact High Speed Design
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
