S7011ACEGA/HCP4A SKF

Temporarily sold out
Worldwide shipping from The Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

S7011ACEGA/HCP4A SKF

The S7011ACEGA/HCP4A SKF is a single row angular contact ball bearing with a hard fiber cage and a rubber seal on two sides.

Stock
not in stock
Brand SKF
Article number S7011ACEGA/HCP4A SKF
Inside diameter 55,00mm
Outside diameter 90,00mm
Width 18,00mm
Product description
Angular Contact Ball Single Row
Read more Show less
Help with this product

Similar to: S7011ACEGA/HCP4A SKF

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 55,00
  2. Outer (D) MM 90,00
  3. Width (B) MM 18,00

Technical details

  1. Availability 0 pcs
  2. Brand SKF
  3. Item number S7011ACEGA/HCP4A SKF
  4. Technical details (ACEGA/HCP4A) ACE=(Segment Contact Angle, Code AC)=25° Contact Angle And (E) Small Size Steel Balls. GA=Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload. HC=(Segment Precision, Code H4)=Bearing Or Bearing Components Of Ceramic. P4A=(P4S-FAG)=(MMV-FAF)=Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4.
  5. Also known as 7316575991586
  6. Category Angular Contact Ball Bearing Single Row
  7. Weight (kg) 0.31
  8. Manufacturer Part Number (MPN) S7011ACEGA/HCP4A
  9. Seal 2RS - Rubber Seal on Two Sides
  10. Cage Type TB - Hard Fiber Cage
  11. Precision H4 - Hybrid / Ceramic Balls / P4
  12. Contact Angle AC - 25° Contact High Speed Design
  13. Pairing G - Universal Pairing
  14. Axial Internal Clearance / Preload GA - Light Preload
  15. Lubrication Standard Lubrication
Show all details Show less
