S61909C TA UP DUL GMN Paul Müller Industrie

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 68
3. Width (B) MM 24
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 2.6772
6. Width (B) Inch 0.9449

Suffix description

1. C 15° Contact Angle
2. TA Laminated Phenolic Resin Cage Or Polyamide Cage Guided On Outer Ring
3. UP GMN Ultra Precision According To GMN Specification
4. DUL 2 Bearings, Universal Matching - Light Preload

Technical details

1. Availability 5 pcs
2. Brand GMN Paul Müller Industrie
3. Item number S61909C TA UP DUL GMN Paul Müller Industrie
4. Also known as 71909CD/P4ADGA
   B71909-C-T-P4S-DUL

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.255

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision UP (Ultra Precision)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
7. Lubrication Standard Lubrication
