RWU55-E-L-V3-G3 INA

All dimensions

1. Inner (d) MM 53,00
2. Outer (D) MM 140,00
3. Width (B) MM 59,00
4. Inner (d) Inch 2.0866
5. Outer (D) Inch 5.5118
6. Width (B) Inch 2.3228

Suffix description

1. E-L Long Carriage
2. V3 Preload
3. G3 Precision Class 3

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number RWU55-E-L-V3-G3 INA
4. Also known as RWU55-E-L-G3-V3

5. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 6.83

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. ECLASS number 23-30-04-90
2. ECLASS2 number 23-30-04-90
3. Medias description Long carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication
