RNAO30X42X16-XL INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 42
3. Width (B) MM 16
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.6535
6. Width (B) Inch 0.6299
7. Under roller diameter (F w) mm 30

Suffix description

1. XL X-Life

Technical details

1. Availability 66 pcs
2. Brand INA
3. Item number RNAO30X42X16-XL INA
4. Also known as 0507759520000
   RNAO30X42X16

5. EAN 4012802735345
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.069

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 33500
2. Radial Dynamic Load Rating Cr (N) 26000
3. Limiting speed (n G) 14600
4. Reference speed (n ϑr) 8500
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings RNAO, without ribs
