RNAO30X40X17-XL INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 40
3. Width (B) MM 17
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.5748
6. Width (B) Inch 0.6693
7. Under roller diameter (F w) mm 30

Suffix description

1. XL X-Life

Technical details

1. Availability 196 pcs
2. Brand INA
3. Item number RNAO30X40X17-XL INA
4. Also known as 0507759440000
   RNAO30X40X17

5. EAN 4012802735338
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.06

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 34000
2. Radial Dynamic Load Rating Cr (N) 22100
3. Limiting speed (n G) 15100
4. Reference speed (n ϑr) 8800
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings RNAO, without ribs
