RNA69/22-XL INA

All dimensions

1. Inner (d) MM 28
2. Outer (D) MM 39
3. Width (B) MM 30
4. Inner (d) Inch 1.1024
5. Outer (D) Inch 1.5354
6. Width (B) Inch 1.1811
7. Under roller diameter (F w) mm 28
8. Width (b) mm 30

Suffix description

1. XL X-Life

Technical details

1. Availability 150 pcs on Thu 17 Sep
2. Brand INA
3. Item number RNA69/22-XL INA
4. Also known as 0507435460000
   RNA69/22

5. EAN 4012802212549
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.0902

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 55000
2. Radial Dynamic Load Rating Cr (N) 42000
3. Limiting speed (n G) 15300
4. Limiting speed for grease lubrication (n G Grease) 9200
5. Reference speed (n ϑr) 8400
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Radial roller bearing RNA..-XL

Downloads and links

1. Download datasheet Download datasheet
2. Link to Manufacturer Link to Manufacturer
3. X-life brochure X-life brochure
