RNA4908-RSR-XL INA

All dimensions

1. Inner (d) MM 48
2. Outer (D) MM 62
3. Width (B) MM 22
4. Inner (d) Inch 1.8898
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.8661
7. Under roller diameter (F w) mm 48

Suffix description

1. RSR One Seal, Buna-N Rubber, Radial Type
2. XL X-Life

Technical details

1. Availability 91 pcs
2. Brand INA
3. Item number RNA4908-RSR-XL INA
4. Also known as 0507730030000
   RNA4908-RSR

5. EAN 4012802701562
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.154

Product Properties

1. Seal RS - Rubber Seal on One Side

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 53000
2. Limiting speed (n G) 5500
3. ECLASS number 23-05-09-07
4. ECLASS2 number 23-05-09-07
5. Medias description Radial roller bearing
