RNA4906-RSR-XL INA

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 47
3. Width (B) MM 17
4. Inner (d) Inch 1.378
5. Outer (D) Inch 1.8504
6. Width (B) Inch 0.6693
7. Under roller diameter (F w) mm 35

Suffix description

1. RSR One Seal, Buna-N Rubber, Radial Type
2. XL X-Life

Technical details

1. Availability 63 pcs
2. Brand INA
3. Item number RNA4906-RSR-XL INA
4. Also known as 0507729880000
   RNA4906-RSR

5. EAN 4012802701982
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.069

Product Properties

1. Seal RS - Rubber Seal on One Side

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 28500
2. Radial Dynamic Load Rating Cr (N) 23900
3. Basic static load rating, radial (C 0r) "28500.0000"
4. Limiting speed (n G) 7500
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings RNA49..-RSR, dimension series 49, lip seal on one side
