RNA4836-XL INA

All dimensions

1. Inner (d) MM 195
2. Outer (D) MM 225
3. Width (B) MM 45
4. Inner (d) Inch 7.6772
5. Outer (D) Inch 8.8583
6. Width (B) Inch 1.7717
7. Under roller diameter (F w) mm 195
8. Width (b) mm 45

Suffix description

1. XL X-Life

Technical details

1. Availability 8 pcs
2. Brand INA
3. Item number RNA4836-XL INA
4. Also known as 0507673720000
   RNA4836

5. EAN 4047643204026
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 2.68

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 550000
2. Radial Dynamic Load Rating Cr (N) 219000
3. Limiting speed (n G) 2420
4. Limiting speed for grease lubrication (n G Grease) 1450
5. Reference speed (n ϑr) 1510
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Radial roller bearing RNA..-XL
